Technical Data
TYPE | OLT-10/15/20/30/50/100/300/500/800/1000JS | |
Total Volume | 10/15/20/30/50/100/300/500/800/1000 | |
Vessel | 316L Stainless Steel | |
Stirrer | Top driven | |
Sterilization | In suit Sterilization(steam source extermal) | |
Basic Features | Temperature,RPM,PH,DO,Antifoam,Feed,Aeration,Pressure | |
Advanced Features | Level,Weight Feed,Multi-Feeds, Mehanol&Ethanol,Exhaust O2&CO2 | |
Controller | OLT-7000 Technical parameter | ||
Parameter | Guideline | Controller data processing function | |
pH | Displaying range: 0.00~14.00±0.01 Auto-control range:2.00~12.00±0.05 Fermentation process control (According to the fermentation time, auto- control pH fluent, at least10 parts) | pH value historical and trend curve analysis Acid, alkali dosage curve analysis Batch report form analysis Acid, alkali total dosage record Keep | |
Antifoam | Automatic PID control and alarm Fermentation process control (According to the fermentation time, auto- control antifoam fluent, at least10 parts) | Antifoam value historical and trend curve analysis Foam error state record antifoam total dosage record Batch report form analysis Keep | |
Rpm | Automatic enactment and control(50~1000rpm±5‰) Fermentation process control (According to the fermentation time, auto-control rev fluent, at least10 parts) | Rpm value historical and trend curve analysis Batch report form analysis Keep and deliver data | |
Temperature | Temperature of cooling water: +5℃-65℃±0.2℃ Fermentation process control (According to the fermentation time, auto- control temperature fluent, at least10 parts) | Temperature value historical and trend curve analysis Batch report form analysis Keep | |
Feeding | PID automatic enactment and control Fermentation process control (According to the fermentation time, auto- control feeding fluent, at least10 parts) | Feeding value historical and trend curve analysis Feeding total dosage record Batch report form analysis keep | |
Pressure | Manual control, instrument display | ||
Air flux | Manual control, instrument display | ||
