Product Description
OLLITAL offers you not only with scalable range of glass and stainless steel bioreactors, but also with multi-parallel and multistep bioreactors. Based on our thorough understanding of bioreactors, rich experience for scaling up benchtop fermentors to processing system, and excellent control system for temperature, rpm, PH, DO, antifoam, feeding, aeration and pressure, you will benefit from our turnkey solution service.
Vessel Technical Data
|
Culture Vessel
|
1L
|
2L
|
3L
|
5L
|
7L
|
10L
|
|
H:D ratio
|
≈1:2
|
|||||
|
Total volume
|
1.1L
|
2.7L
|
3.5L
|
5.8L
|
7.9L
|
11.2L
|
|
Working volume
|
0.8L
|
2.0L
|
2.6L
|
4.4L
|
6.0L
|
8.4L
|
|
Minimal working volume
|
0.3L
|
0.7L
|
0.9L
|
1.5L
|
2.0L
|
2.8L
|
|
Agitation speed range
|
5~1000rpm
|
|||||
|
Motorpower
|
0.18Kw
|
0.4Kw
|
0.4Kw
|
0.4Kw
|
0.4Kw
|
0.75Kw
|
|
Impeller to vessel diameter ratio
|
1:2
|
|||||
|
Surface treatment
|
Inner vessel Ra ≤ 0.4 um，Outer surface Ra＜0.6 um
|
|||||
|
Material | Pressure
|
SUS316L, Borosilicat glass| | 0.10Mpa（Max 0.15Mpa）
|
|||||
|
Vessel Configuration
|
||||||
|
Low noise stirring motor
|
●
|
|||||
|
Autoclavable sterilization | Sterilization in place
|
● | ○
|
|||||
|
Magnetic drive | mechanical drive
|
● | ○
|
|||||
|
Storage bottle [2pcs]
|
●
|
|||||
|
Exhaust condenser [water cooling]
|
●
|
|||||
|
Customizable blade
|
○
|
|||||
|
Custom port
|
○
|
|||||
|
Electrical heating | Jacketed heating
|
● | ○
|
|||||
Cumstom Service
